CFORCE 1000
THE BEAST
MOST POWERFUL CFORCE ATV
MOST POWERFUL CFORCE ATV
Engine
V-Twin cylinder, Liquid cooled, 4-stroke, SOHC, 8-Valve
Dimensions
L: 2395 W: 1264 H: 1420 mm
1480 mm wheelbase
1480 mm wheelbase
Suspension
Front: Dual A-arm independent suspension
Rear: Trailing Arm independent suspension
Rear: Trailing Arm independent suspension
Power
962.6 cc
Max speed 110 km/h
Max power 55 kW / 7250 rpm
Max speed 110 km/h
Max power 55 kW / 7250 rpm
Seat Height
585 mm
Brakes
Hydraulic
Performance
10.6±0.5:1 Compression ratio
72 Nm / 6500 rpm Max torque
72 Nm / 6500 rpm Max torque
Clearance
Minimum 285 mm
Rims
Front: 14 x 7.0 AT
Rear: 14 x 8.0 AT
Rear: 14 x 8.0 AT
Transmission
Automatic (CVT)
Weight
490 kg Curbweight
240 kg Payload capacity
240 kg Payload capacity
Tyre
Front: 27 x 9-14
Rear: 27 x 11-14
Rear: 27 x 11-14
