Engine
2 cylinder inline, Liquid cooled
DOHC, 8-Valve
EURO5
DOHC, 8-Valve
EURO5
Dimensions
L: 2234 W: 853 H:1277 mm
1531 mm wheelbase
1531 mm wheelbase
Suspension
Fully adjustable KYB suspension
Front: KYB upside down (160mm)
Rear: Mono (150mm)
Front: KYB upside down (160mm)
Rear: Mono (150mm)
Power
799 cc
Max speed 180 km/h
Max power 67 kW / 9250 rpm
Max speed 180 km/h
Max power 67 kW / 9250 rpm
Seat Height
825 mm
Brakes
Front: Hydraulic disc brakes. Dual 320mm J.Juan
Rear: Hydraulic disc brakes. 260mm J.Juan
Rear: Hydraulic disc brakes. 260mm J.Juan
Performance
12.7: 1 Compression ratio
75 Nm / 8000 rpm Max torque
75 Nm / 8000 rpm Max torque
Clearance
Minimum 190 mm
Rims
Front: 19" Cross-spoke wheel
Rear: 17" Cross-spoke wheel
Rear: 17" Cross-spoke wheel
Transmission
6 Gears, Manual
Weight
231 kg Curbweight
150 kg Payload capacity
150 kg Payload capacity
Tyre
Front: 110/80 R19
Rear: 150/70 R17
Maxxis Maxventure
Rear: 150/70 R17
Maxxis Maxventure
